PES-1014 User’s Guide
Statistics 9-5
9.5 Packet Analysis (RX)
Move the cursor over the Statistics link and click Packet Analysis(RX) to display the Packet Analysis (RX)
screen shown next.
Figure 9-5 Packet Analysis (RX)
Table 9-4 Packet Analysis (RX) Description
FIELD DESCRIPTION
Port ID This is the label of a port.
64 in_length The number of packets (including bad packets) received that were 64 octets in length.
65-127 The number of packets (including bad packets) received that were between 65 and 127
octets in length.
128-255 The number of packets (including bad packets) received that were between 128 and 255
octets in length.
256-511 The number of packets (including bad packets) received that were between 256 and 511
octets in length.
512-1023 The number of packets (including bad packets) received that were between 512 and 1023
octets in length
1024-1518 The number of packets (including bad packets) received that were between 1024 and 1518
octets in length.
