ZyXEL Communications PES-1014 - Manual (Page 34)

PES-1014 User’s Guide
4-8 System
4.7 Save Changes
Move the cursor over the System link and click Save Changes to display the Save Changes screen shown next. All
the settings mentioned above are stored only in working memory and are lost after the power is turned off. After
you configure settings, use the following procedure to store them:
Step 1. Click Apply.
Step 6. Click System in Information, and then Save Changes.
Step 2. Click Save to save the settings into flash memory.
Restart the device (see 3.4.4) to store the settings in long term memory.
Figure 4-8 Save Changes
4.8 Firmware Upgrade
Use Internet Explorer 5.0 or later to upgrade the firmware.
Do not interrupt the upgrade process (interrupting it causes an error).
Restart the switch immediately after the upgrade is completed.
Move the cursor over the System link and click Software Upgrade to display the Firmware Upgrade screen
shown next.
•
Download the new version software file through Internet by web browser or FTP server.
Figure 4-9 Firmware Upgrade
•
The system will complete the upgrade process automatically.
•
Restart the device to finish the upgrade process.
Click Browse
and choose the
file stored on
your computer
Click
Upgrade
