PES-1014 User’s Guide
2-2 Hardware Overview
LED COLOR STATUS DESCRIPTION
SNMP Green
PSR Green
SRD Green
STD Green
These LEDs are used in a diagnostic test when the PES-1014 turns on.
They turn on and off one-by-one in the following order: SNMP> PSR>
SRD> STD. After this the SNMP will turn on again and remain on.
A, B (these are the Ethernet ports)
On The port is connected to a 100Mbps Ethernet.
10/100 Green
Off The port is connected to a 10Mbps Ethernet.
Blinking The port link is sending/receiving data.
ACT/LINK Green
Off The port link is down.
1-14 (these are the phoneline ports)
On The phoneline networking link is up. LINK Green
Off The phoneline networking link is down.
Blinking The phoneline networking link is sending/receiving data. ACT Green
Off The phoneline networking link is not sending/receiving data.
2.2 Console Port
Connect the manager computer to the PES-1014’s console port using a straight-through Ethernet cable.
2.3 Ethernet Port Connections
EHTERNET PORT ETHERNET CABLE TYPE
ETHERNET A MDI-X Straight-through or cross-over
ETHERNET B MDI Straight-through
Figure 2-2
Connect ETHERNET port A to a switch or router. You may use either a straight-through or a cross-over cable
since ETHERNET port A MDI-X automatically detects and adjusts to the type of equipment to which it is
connected.
Use a straight-through Ethernet cable to connect ETHERNET port B MDI to a switch or router.
