AES-100 User’s Guide
13-4 Firmware Upload and Recovery
Figure 13-3 Database Edit Dialog
7. Select Normal Bootp to enable normal BOOTP/TFTP functions.
Figure 13-4 Enable BOOTP/TFTP
8. Restart the ADSL Networking Module and press any key within three seconds to get the following
screen.
Figure 13-5 Enter Debug Mode
9. Press any key at the “Press any key within 3 seconds to enter debug mode
………………” message, to enter the debug mode.
10. Enter atnb at the ADSL Networking Module boot console.
SDRAM Testing ...
Mac address 00:A0:C5:12:34:56
Press any key within 3 seconds to enter debug mode
.............................
