AES-100 User’s Guide
Bridge Commands 7-9
This command lets you allocate IEEE 802.1Q identification numbers (tags) on a port-by-port basis.
The command 192.168.1.1 bridge> pvid displays the default port identification of all ADSL Networking
Module ports.
The IEEE 802.1Q standard uses an explicit tag in the header to specify the VLAN ID (VID) of an Ethernet frame.
In this way, the VLAN membership of a frame can be carried across switches. The following table displays the
physical port and corresponding default PVID tag on the AES-100.
Table 7-1 Physical Ports, Port Numbers and AES-100 Default PVID Tags in Fast Mode
PHYSICAL
PORT
PORT
NUMBER
DEFAULT PVID TAG
CPU (Central Processing Unit) 0 1
ADSL Networking Module LAN
Port (Ethernet) 1 N/A
ADSL Port 1 2 2
ADSL Port 2 3 3
ADSL Port 3 4 4
ADSL Port 4 5 5
ADSL Port 5 6 6
ADSL Port 6 7 7
ADSL Port 7 8 8
ADSL Port 8 9 9
