AES-100 User’s Guide
IEEE 802.1Q Tagged VLAN Commands 8-7
8.5.9 DVLAN List Command
Syntax:
192.168.1.1 vlan1q> dvlan list
This command displays the dynamic VLAN registration table. The following figure is an example of what is
displayed when you use this command.
Figure 8-6 Example: DVLAN List Command Display
In the figure above, “||” denotes “filter” and “>>” denotes “forward”.
8.5.10 DVLAN Getentry Command
Syntax:
192.168.1.1 vlan1q> dvlan getentry
where
= VLAN ID. Valid parameter range = [1 – 4094].
This command displays an entry with a specified VLAN ID in dynamic GVRP table.
Display a Dynamic VLAN Table Entry Example
The following figure is an example display of the following command.
192.168.1.1 vlan1q> dvlan getentry 2
Figure 8-7 Example: DVLAN Getentry 2 Command Display
In the figure above, “||” denotes “filter” and “>>” denotes “forward”.
8.5.11 VLAN List Command
Syntax:
192.168.1.1 vlan1q> vlan list
This command displays the entire VLAN table. The display refreshes periodically. Press [ENTER] and then enter
the stop command to stop the display from refreshing. The following figure is an example what is displayed when
you use this command.
vid 01 02 03 04 05 06 07 08 09
---- ---- ---- ---- ---- ---- ---- ---- ---- ----
2 || >> || || >> >> || || >>
vid 01 02 03 04 05 06 07 08 09
---- ---- ---- ---- ---- ---- ---- ---- ---- ----
2 || >> || || >> >> || || >>
3 >> >> || || || >> >> >> ||
4 >> || || >> >> || || >> >>
5 || >> || || >> >> || || >>
6 >> >> || || || >> >> >> ||
7 || >> || >> >> || || >> >>
8 >> || || >> || >> >> >> >>
9 || >> || || || >> || >> >>
