AES-100 User’s Guide
IEEE 802.1p Priority Commands 9-1
Chapter 9
IEEE 802.1p Priority Commands
This chapter explains IEEE 802.1p Priority CI Commands.
9.1 Introduction
IEEE 802.1p Priority CI Commands provide priority regeneration for ports. IEEE 802.1p defines up to eight
priorities (0-7) by inserting a tag into a MAC-layer frame that contains bits to define priority of service.
9.2 IEEE 802.1p Priority Commands
Bridge port 1 stands for the Ethernet port, bridge port 2 stands for ADSL port 1, bridge port 3 stands for
ADSL port 2, and so on.
9.2.1 Priority Port Command
Syntax:
192.168.1.1 vlan1q> priority port
where
= bridge port number. Valid parameter range = [1 - 9].
= default priority for the specified port. Valid parameter range = [0 - 7], where 0 is
the lowest priority and 7 is the highest priority.
This command sets the default priority for an ingress port.
To display the default port priority table, simply use the Priority Port command without parameters, as shown
next.
192.168.1.1 vlan1q> priority port
9.2.2 Regen Port Command
Syntax:
192.168.1.1 vlan1q> regen port [ ]
where
= bridge port number. Valid parameter range = [1 – 9].
= the user priority for a frame received on this port. Valid parameter
range = [0 - 7], where 0 is the lowest priority and 7 is the highest
priority.
= the regenerated user priority the incoming user priority is mapped to for
. Valid parameter range = [0 - 7], where 0 is the lowest
priority and 7 is the highest priority.
