AES-100 User’s Guide
Hardware Overview 2-1
Chapter 2
Hardware Overview
This chapter gives a brief introduction to the AES-100 hardware.
2.1 Unpacking the AES-100
Before installing, check to see that all the components of the AES-100 are included in the package.
2.2 Additional Installation Requirements
In addition to the contents of the package, you need the following hardware and software components before you
install and use your product:
• A computer with Ethernet 10Base-T or 100Base-TX NIC (Network Interface Card)
• WAN service provided by a local phone company
• A computer with terminal emulation software configured to the following parameters:
ƒ VT100 terminal emulation
ƒ 9600 bps
ƒ No parity, 8 data bits, 1 stop bit
ƒ No flow control
2.3 Front Panel
The following figure shows the front panel of the AES-100.
