Color Calibration Process for v1.1.6 Software Xerox 490/980 Color Continuous Feed Printing System
5-26 Color Management Guide
11. Select the [Color] tab.
12. In the Color Characteristics [Upstream] box, in the Printer Name drop-down menu, select
[PRINTER1].
13. In the Color Characteristics [Upstream] box, select [Setting].
14. In the User TRC drop-down menu, select [Upstream.trc].
15. In the Resource Group Name drop-down menu, select [TRC_PRINTER1.cntl].
16. Select [OK].
17. In the Color Characteristics [Downstream] box, in the Printer Name drop-down menu, select
[PRINTER2].
18. In the Color Characteristics [Downstream] box, select [Setting].
19. In the User TRC drop-down menu, select [Downstream.trc].
20. In the Resource Group Name drop-down menu, select [TRC_PRINTER2.cntl].
21. Select [OK].
