Xerox 490/980 Color Continuous Feed Printing System

Color Calibration Process for v1.1.6 Software

Color Management Guide

5-17

Click into the fourth field down from the top of the window. Delete the _1 from the end of
the filename (ends with .trc).

Note

The TRC Viewer will automatically process the Upstream_1.txt, Upstream_2.txt,
Upstream_3.txt files and average the results. The same process applies to the
Downstream_1.txt, Downstream_2.txt and Downstream_3.txt files.

Select [TRC??].

Select [OK] after the pop-up window appears.

Repeat steps 3-8 for the downstream engine using file Downstream_1.txt.

10. Select the bottom right [???] to close the TRC Viewer Software.

Create TRC

Refresh

Exit

Edit name of TRC

Browse for input file
