Xerox COLOR 490 - Manual (Page 56)

Pre-Calibration Engine Density Adjustment Xerox 490/980 Color Continuous Feed Printing System
4-16 Color Management Guide
12. Select the [Color] tab.
13. In the Color Characteristics [Upstream] box, in the Printer Name drop-down menu, select
[PRINTER1].
14. In the Color Characteristics [Upstream] box, select [Setting].
15. In the Resource Group Name drop-down menu, select [TRC_PRINTER1.cntl].
16. Select [OK].
17. In the Color Characteristics [Downstream] box, in the Printer Name drop-down menu, select
[PRINTER2].
18. In the Color Characteristics [Downstream] box, select [Setting].
19. In the Resource Group Name drop-down menu, select [TRC_PRINTER2.cntl].
20. Select [OK].
