Prestige 2602H/HW Series User’s Guide
Chapter 1 Getting To Know Your Prestige
57
Refer to the Quick Start Guide for information on hardware connections.
LAN 1-4
Green
On
The Prestige has a successful Ethernet connection.
Blinking
The Prestige is sending/receiving data.
None
Off
The LAN is not connected.
WLAN (W
models only)
Green
On
The Prestige is ready, but is not sending/receiving data
through the wireless LAN.
Blinking
The Prestige is sending/receiving data through the wireless
LAN.
None
Off
The wireless LAN is not ready or has failed.
DSL
Green
On
The Prestige has a DSL connection.
Blinking
The Prestige is initializing the DSL line.
None
Off
The DSL link is down.
INTERNET
Green
On
The Prestige has an IP connection but no traffic.
The Prestige has a WAN IP address (either static or assigned
by a DHCP server), PPP negotiation was successfully
completed (if used) and the DSL connection is up.
Blinking
The Prestige is sending or receiving IP traffic.
Red
On
The Prestige attempted to make an IP connection but failed.
Possible causes are no response from a DHCP server, no
PPPoE response, PPPoE authentication failed).
None
Off
The Prestige does not have an IP connection
PHONE 1, 2
Green
On
A SIP account is registered for the phone port.
Blinking
A telephone connected to the phone port has its receiver off
of the hook or there is an incoming call.
None
Off
The phone port does not have a SIP account registered.
Table 4 P2602H/HW-C Series Front Panel LEDs (continued)
LED
COLOR
STATUS
DESCRIPTION
