Prestige 2602H/HW Series User’s Guide
424 Chapter 43 VPN/IPSec Setup
Figure 261 Menu 27 VPN/IPSec Setup
43.2 IPSec Summary Screen
Type 1 in menu 27 and then press [ENTER] to display Menu 27.1 IPSec Summary. This is a
summary read-only menu of your IPSec rules (tunnels). Edit or create an IPSec rule by
selecting an index number and then configuring the associated submenus.
Figure 262 Menu 27.1 IPSec Summary
Menu 27 - VPN/IPSec Setup
1. IPSec Summary
2. SA Monitor
Enter Menu Selection Number:
Menu 27.1 – IPSec Summary
# Name A Local Addr Start - Addr End / Mask Encap IPSec Algorithm
Key Mgt Remote Addr Start - Addr End / Mask Secure Gw Addr
- ------ - ----------------- --------------- ------ ------------------
001 Taiwan Y 192.168.1.35 192.168.1.38 Tunnel ESP AES MD5
IKE 172.16.2.40 172.16.2.46 193.81.13.2
002 zw50 N 1.1.1.1 1.1.1.1 Tunnel AH SHA1
IKE 4.4.4.4 255.255.0.0 zw50test.zyxel.
003 China N 192.168.1.40 192.168.1.42 Tunnel ESP DES MD5
IKE N/A N/A 0.0.0.0
004
005
Select Command= None Select Rule= N/A
Press ENTER to Confirm or ESC to Cancel:
Table 147 Menu 27.1 IPSec Summary
FIELD DESCRIPTION
# This is the VPN policy index number.
Name This field displays the unique identification name for this VPN rule. The name may be up
to 32 characters long but only 10 characters will be displayed here.
