P-2602H(W)(L)-DxA Series User’s Guide
Chapter 2 Introducing the Web Configurator
53
The icons provide the following functions.
2.2.2 Navigation Panel
Use the menu items on the navigation panel to open screens to configure ZyXEL Device
features. The following tables describe each menu item.
Table 5 Web Configurator Icons in the Title Bar
ICON
DESCRIPTION
Help: Click this icon to open up help screens.
Wizards: Click this icon to go to the configuration wizards. See
for more information.
Logout: Click this icon to log out of the web configurator.
Table 6 Navigation Panel Summary
LINK
TAB
FUNCTION
Status
This screen contains administrative and system-related information.
Network
WAN
Internet
Connection
Use this screen to configure ISP parameters, WAN IP address assignment,
DNS servers and other advanced properties.
LAN
IP
Use this screen to configure LAN TCP/IP settings, enable Any IP and other
advanced properties.
DHCP Setup
Use this screen to configure LAN DHCP settings.
Client List
Use this screen to view current DHCP client information and to always
assign specific IP addresses to individual MAC addresses (and host
names).
IP Alias
Use this screen to partition your LAN interface into subnets.
Wireless LAN
(“W” models
only)
General
Use this screen to configure the wireless LAN settings and WLAN
authentication/security settings.
OTIST
Use this screen to assign your wireless security settings to wireless clients.
MAC Filter
Use this screen to configure the ZyXEL Device to give exclusive access to
specific wireless clients or exclude specific wireless clients from accessing
the ZyXEL Device.
QoS
WMM QoS allows you to prioritize wireless traffic according to the delivery
requirements of individual services.
Local User
Database
Use this screen to set up built-in user profiles for wireless station
authentication.
NAT
General
Use this screen to enable NAT.
Port Forwarding
Use this screen to make your local
servers visible to the outside world.
Address Mapping Use this screen to configure network address translation mapping rules.
VoIP
SIP
SIP Settings
Use this screen to configure your ZyXEL Device’s Voice over IP settings.
QoS
Use this screen to configure your ZyXEL Device’s Quality of Service
settings for VoIP.
