P-2602H(W)(L)-DxA Series User’s Guide
48 Chapter 1 Getting To Know the ZyXEL Device
Refer to the Quick Start Guide for information on hardware connections.
DSL Green On Your device has a DSL connection.
Blinking Your device is initializing the DSL line.
None Off The DSL link is down.
INTERNET Green On Your device has an IP connection but no traffic.
Your device has a WAN IP address (either static or assigned
by a DHCP server), PPP negotiation was successfully
completed (if used) and the DSL connection is up.
Blinking Your device is sending or receiving IP traffic.
Red On Your device attempted to make an IP connection but failed.
Possible causes are no response from a DHCP server, no
PPPoE response, PPPoE authentication failed).
None Off Your device does not have an IP connection
PHONE 1, 2 Green On A SIP account is registered for the phone port.
Blinking A telephone connected to the phone port has its receiver off
of the hook or there is an incoming call.
Orange On A SIP account is registered for the phone port and there is a
voice message in the corresponding SIP account.
Blinking A telephone connected to the phone port has its receiver off
of the hook and there is a voice message in the
corresponding SIP account.
None Off The phone port does not have a SIP account registered.
Table 4 LEDs (continued)
LED COLOR STATUS DESCRIPTION
