P-2602H(W)(L)-DxA Series User’s Guide
Chapter 26 Diagnostic
315
C
H A P T E R
26
Diagnostic
These read-only screens display information to help you identify problems with the ZyXEL
Device.
26.1 General Diagnostic
Click Maintenance > Diagnostic to open the screen shown next.
Figure 183 Diagnostic: General
The following table describes the fields in this screen.
26.2 DSL Line Diagnostic
Click Maintenance > Diagnostic > DSL Line to open the screen shown next.
Table 123 Diagnostic: General
LABEL
DESCRIPTION
TCP/IP
Address
Type the IP address of a computer that you want to ping in order to test a connection.
Ping
Click this button to ping the IP address that you entered.
