Page 80
528150-YTG-C-1109
80
Johnson Controls Unitary Products
Indoor Blower Specifications
Size
(Tons)
Model
Motor
Motor Sheave
Blower Sheave
Belt
HP
RPM
Eff.
SF
Frame
Datum Dia.
(in.)
Bore (in.)
Model
Datum Dia.
(in.)
Bore (in.)
Model
037
(3)
ZH
1-1/2
1725
0.8
1.15
56
2.0 - 3.0
7/8
1VM34
6.5
1
AK69
A47
1-1/2
1725
0.8
1.15
56
3.0 - 4.0
7/8
1VL44
6.5
1
AK69
A47
049
(4)
ZH
1-1/2
1725
0.8
1.15
56
2.0 - 3.0
7/8
1VM34
5.2
1
AK56
A47
1-1/2
1725
0.8
1.15
56
3.0 - 4.0
7/8
1VL44
5.2
1
AK56
A47
061
(5)
ZH
1-1/2
1725
0.8
1.15
56
2.6 - 3.6
7/8
1VL40
5.7
1
AK61
A47
2
1725
0.8
1.15
56
4.2 - 5.2
7/8
1VP56
7.0
1
AK74
A54
078
(6.5)
ZH
1-1/2
1725
0.8
1.15
56
3.4 - 4.4
7/8
1VM50
7.0
1
AK74
A49
2
1725
0.8
1.15
56
3.4 - 4.4
7/8
1VM50
6.0
1
AK64
A49
090
(7.5)
ZH
1-1/2
1725
0.8
1.15
56
3.4 - 4.4
7/8
1VM50
7.0
1
AK74
A49
3
1725
0.8
1.15
56
3.4 - 4.4
7/8
1VM50
5.7
1
AK61
A49
102
(8.5)
ZH
2
1725
0.8
1.15
56
3.4 - 4.4
7/8
1VM50
9.0
1
AK94
A56
3
1725
0.8
1.15
56
3.4 - 4.4
7/8
1VM50
7.0
1
AK74
A54
120
(10)
ZH
2
1725
0.8
1.15
56
3.4 - 4.4
7/8
1VM50
8.0
1
AK84
A56
3
1725
0.8
1.15
56
3.4 - 4.4
7/8
1VM50
7.0
1
AK74
A54
150
(12.5)
ZH
3
1725
0.8
1.15
56
3.4 - 4.4
7/8
1VM50
7.0
1
AK74
A54
5
1725
0.87
1.15
184T
4.3 - 5.3
1-1/8
1VP56
6.7
1
BK77
BX55
037
(3)
ZJ
1-1/2
1725
0.8
1.15
56
2.0 - 3.0
7/8
1VM34
6.5
1
AK69
A47
1-1/2
1725
0.8
1.15
56
3.0 - 4.0
7/8
1VL44
6.5
1
AK69
A47
049
(4)
ZJ
1-1/2
1725
0.8
1.15
56
2.0 - 3.0
7/8
1VM34
5.2
1
AK56
A47
1-1/2
1725
0.8
1.15
56
3.0 - 4.0
7/8
1VL44
5.2
1
AK56
A47
061
(5)
ZJ
1-1/2
1725
0.8
1.15
56
2.6 - 3.6
7/8
1VL40
5.7
1
AK61
A47
2
1725
0.8
1.15
56
4.2 - 5.2
7/8
1VP56
7.0
1
AK74
A54
078
(6.5)
ZJ
1-1/2
1725
0.8
1.15
56
2.6 - 3.6
7/8
1VL40
7.0
1
AK74
A53
2
1725
0.8
1.15
56
3.6 - 4.6
7/8
1VM50
7.0
1
AK74
A54
090
(7.5)
ZJ
1-1/2
1725
0.8
1.15
56
2.6 - 3.6
7/8
1VL40
6.5
1
AK69
A53
3
1725
0.8
1.15
56
3.6 - 4.6
7/8
1VM50
6.5
1
AK69
A54
102
(8.5)
ZJ
2
1725
0.8
1.15
56
3.4 - 4.4
7/8
1VM50
8.5
1
AK89
A56
3
1725
0.8
1.15
56
3.4 - 4.4
7/8
1VM50
7.0
1
AK74
A54
120
(10)
ZJ
2
1725
0.8
1.15
56
3.4 - 4.4
7/8
1VM50
8.0
1
AK84
A56
3
1725
0.8
1.15
56
3.4 - 4.4
7/8
1VM50
7.0
1
AK74
A54
150
(12.5)
ZJ
3
1725
0.8
1.15
56
3.4 - 4.4
7/8
1VM50
7.0
1
AK74
A54
5
1725
0.87
1.15
184T
4.3 - 5.3
1-1/8
1VP56
6.7
1
BK77
BX55
Power Exhaust Specifications
Model
Voltage
Motor
Motor
Fuse Size
CFM @
0.1 ESP
HP
RPM
1
1. Motors are multi-tapped and factory wired for high speed.
QTY
LRA
FLA
MCA
2PE04703225
208/230-1-60
3/4
1075
1
7.8
5
6.3
10
3800
2PE04703246
460-1-60
3/4
1075
1
3.4
2.2
2.8
5
3800
2PE04703258
575-1-60
3/4
1050
1
2.9
1.5
1.9
4
3800
Electric Heat Multipliers
Voltage
kW Capacity Multipliers
1
1. Electric heaters are rated at nominal voltage. Use this table to determine the electric heat
capacity for heaters applied at lower voltages.
Nominal
Applied
240
208
0.75
230
0.92
480
460
0.92
600
575
0.92
