Zh/zj037-150 transition roof curb, Zh/zj037-150 economizer assembly – York PREDATOR R-410A User Manual
Page 132
528150-YTG-C-1109
132
Johnson Controls Unitary Products
ZH/ZJ037-150 Transition Roof Curb
ZH/ZJ037-150 Economizer Assembly
76-5/8
94
50-1/2
30-1/2
64-1/4
59-1/4
10
23 4
26
80-5/8
2 TYP
FRONT
RIGHT
SUPPLY
RETURN
35 3/4
Outside Air
Intake Hood
26
25 3/4
30 1/4
26
39 1/2
or
47 1/2
Relief Hood for
Power Exhaust or
Barometric Relief
88 1/4
58 1/4
