York PREDATOR R-410A - Manual (Page 104)

528150-YTG-C-1109
104 Johnson Controls Unitary Products
ZJ078-150 Hi Static Motor - With Powered Convenience Outlet
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Exh
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA 1
(Amps)
MCA 1
w/Pwr
Exh
(Amps)
Max Fuse 2 /
Breaker 3
Size
(Amps)
Max Fuse 2 /
Breaker 3
Size w/ Pwr
Exh
(Amps)
RLA LRA MCC FLA FLA FLA FLA Model kW Stages Amps
078
(6.5)
208 9.3 68 14.5 1.5 6.8 5.5 10.0
None - - - 40.9 46.4 50 50
E09 6.8 1 18.9 44.6 51.5 50 60
E18 13.5 2 37.5 67.8 74.7 70 80
E24 18 2 50.0 83.5 90.3 90 100
E36 25.5 2 70.8 109.5 116.4 110 125
230 9.3 68 14.5 1.5 6.8 5.5 10.0
None - - - 40.9 46.4 50 50
E09 9 1 22.6 48.1 54.9 50 60
E18 18 2 45.2 75.1 82 80 90
E24 24 2 60.2 93.2 100 100 100
E36 34 2 85.3 123.2 130.1 125 150
460 4.9 34 7.6 0.8 3.4 2.2 5.0
None - - - 21.1 23.3 25 25
E09 9 1 11.3 24 26.8 25 30
E18 18 2 22.6 37.6 40.3 40 45
E24 24 2 30.1 46.6 49.3 50 50
E36 34 2 42.7 61.6 64.4 70 70
575 3.8 28 6 0.6 2.7 1.8 4.0
None - - - 16.5 18.3 20 20
E09 9 1 9.0 19.2 21.5 20 25
E18 18 2 18.1 30 32.3 30 35
E24 24 2 24.1 37.2 39.5 40 40
E36 34 2 34.1 49.3 51.5 50 60
090
(7.5)
208 11.9 88.0 18.5 3.5 9.6 5.5 10.0
None - - - 53.4 58.9 60 70
E09 6.8 1 18.9 53.4 58.9 60 70
E18 13.5 2 37.5 71.3 78.2 80 80
E24 18.0 2 50.0 87 93.8 90 100
E36 25.5 2 70.8 113 119.9 125 125
230 11.9 88.0 18.5 3.5 9.6 5.5 10.0
None - - - 53.4 58.9 60 70
E09 9.0 1 22.6 53.4 58.9 60 70
E18 18.0 2 45.2 78.6 85.5 80 90
E24 24.0 2 60.2 96.7 103.5 100 110
E36 34.0 2 85.3 126.7 133.6 150 150
460 5.2 44.0 8.1 1.6 4.8 2.2 5.0
None - - - 24.7 26.9 25 30
E09 9.0 1 11.3 25.8 28.5 30 30
E18 18.0 2 22.6 39.3 42.1 40 45
E24 24.0 2 30.1 48.3 51.1 50 60
E36 34.0 2 42.7 63.4 66.1 70 70
575 4.8 36.0 7.5 1.3 3.9 1.8 4.0
None - - - 21.3 23.1 25 25
E09 9.0 1 9.0 21.3 23.1 25 25
E18 18.0 2 18.1 31.5 33.8 35 35
E24 24.0 2 24.1 38.7 41 40 45
E36 34.0 2 34.1 50.8 53 60 60
102
(8.5)
208 12.2 88 19 3.5 9.6 5.5 10.0
None - - - 54.1 59.6 60 70
E09 6.8 1 18.9 54.1 59.6 60 70
E18 13.5 2 37.5 71.3 78.2 80 80
E24 18 2 50.0 87 93.8 90 100
E36 25.5 2 70.8 113 119.9 125 125
230 12.2 88 19 3.5 9.6 5.5 10.0
None - - - 54.1 59.6 60 70
E09 9 1 22.6 54.1 59.6 60 70
E18 18 2 45.2 78.6 85.5 80 90
E24 24 2 60.2 96.7 103.5 100 110
E36 34 2 85.3 126.7 133.6 150 150
460 5.8 44 9 1.6 4.8 2.2 5.0
None - - - 26.1 28.3 30 30
E09 9 1 11.3 26.1 28.5 30 30
E18 18 2 22.6 39.3 42.1 40 45
E24 24 2 30.1 48.3 51.1 50 60
E36 34 2 42.7 63.4 66.1 70 70
575 4.4 36 5.5 1.3 3.9 1.8 4.0
None - - - 20.4 22.2 25 25
E09 9 1 9.0 20.7 23 25 25
E18 18 2 18.1 31.5 33.8 35 35
E24 24 2 24.1 38.7 41 40 45
E36 34 2 34.1 50.8 53 60 60
