528150-YTG-C-1109
74 Johnson Controls Unitary Products
Additional Static Resistance - 037 thru 061
Size
(Tons)
Model CFM Cooling Only 1
1. Add these values to the available static resistance in the respective Blower Performance Tables.
Economizer 2 3
2. Deduct these values from the available external static pressure shown in the respective Blower Performance Tables.
3. The pressure drop through the economizer is greater for 100% outdoor air than for 100% return air. If the resistance of the return air duct
is less than 0.25 IWG, the unit will deliver less CFM during full economizer operation.
4” Pleated Filter 2
Electric Heat kW 2
3 6 9 15 20 24
037 (3)
049 (4)
ZH/ZJ
900 0.05 -0.05 0.01 TBA TBA TBA TBA TBA TBA
1000 0.05 -0.03 0.02 TBA TBA TBA TBA TBA TBA
1100 0.04 -0.02 0.03 TBA TBA TBA TBA TBA TBA
1200 0.04 0.00 0.04 TBA TBA TBA TBA TBA TBA
1300 0.03 0.01 0.05 TBA TBA TBA TBA TBA TBA
1400 0.03 0.03 0.07 TBA TBA TBA TBA TBA TBA
1500 0.03 0.04 0.08 TBA TBA TBA TBA TBA TBA
1600 0.02 0.06 0.09 TBA TBA TBA TBA TBA TBA
1700 0.02 0.07 0.10 TBA TBA TBA TBA TBA TBA
1800 0.01 0.08 0.11 TBA TBA TBA TBA TBA TBA
1900 0.01 0.10 0.13 TBA TBA TBA TBA TBA TBA
2000 0.00 0.11 0.14 TBA TBA TBA TBA TBA TBA
061 (5) ZH/ZJ
1500 -0.01 0.13 0.07 TBA TBA TBA TBA TBA TBA
1600 -0.01 0.14 0.08 TBA TBA TBA TBA TBA TBA
1700 -0.01 0.15 0.08 TBA TBA TBA TBA TBA TBA
1800 -0.02 0.16 0.09 TBA TBA TBA TBA TBA TBA
1900 -0.02 0.17 0.10 TBA TBA TBA TBA TBA TBA
2000 -0.02 0.18 0.10 TBA TBA TBA TBA TBA TBA
2100 -0.03 0.19 0.11 TBA TBA TBA TBA TBA TBA
2200 -0.03 0.20 0.12 TBA TBA TBA TBA TBA TBA
2300 -0.04 0.21 0.12 TBA TBA TBA TBA TBA TBA
2400 -0.04 0.22 0.13 TBA TBA TBA TBA TBA TBA
2500 -0.05 0.23 0.14 TBA TBA TBA TBA TBA TBA
