York PREDATOR R-410A - Manual (Page 37)

528150-YTG-C-1109
Johnson Controls Unitary Products 37
ZH090 (7.5 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity 1
(MBh)
Total
Input
(kW) 2
Sensible Capacity (MBh) Total
Capacity 1
(MBh)
Total
Input
(kW) 2
Sensible Capacity (MBh)
CFM
WB
(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1875
77 113.8 5.8 49.0 41.0 33.1 - - - 112.1 6.5 46.6 38.6 30.6 - - -
72 106.0 5.8 62.6 54.6 46.7 38.7 - - 102.9 6.4 59.9 51.9 43.9 35.9 - -
67 98.1 5.8 76.2 68.3 60.3 52.3 44.4 - 93.8 6.4 73.2 65.2 57.2 49.2 41.2 -
62 86.5 5.8 86.5 80.4 71.9 64.0 56.0 48.1 83.9 6.4 83.9 79.0 68.5 60.5 52.5 44.4
2250
77 121.4 5.8 54.8 45.5 36.3 - - - 116.8 6.5 51.9 42.7 33.5 - - -
72 112.9 5.8 69.7 60.4 51.2 41.9 - - 107.3 6.4 66.5 57.2 48.0 38.8 - -
67 104.5 5.8 84.6 75.3 66.1 56.8 47.5 - 97.7 6.4 81.0 71.8 62.6 53.3 44.1 -
62 92.2 5.8 92.2 88.1 78.8 69.6 60.3 51.0 87.5 6.4 87.5 84.1 74.9 65.7 56.5 47.3
57 90.4 5.8 90.4 91.7 85.4 76.2 66.9 57.6 87.7 6.4 87.7 87.7 80.0 70.7 61.5 52.3
2625
77 128.9 5.8 60.6 50.0 39.4 - - - 121.5 6.5 57.2 46.8 36.3 - - -
72 119.9 5.8 76.8 66.2 55.6 45.0 - - 111.6 6.5 73.0 62.6 52.1 41.7 - -
67 110.9 5.9 93.0 82.4 71.9 61.3 50.7 - 101.7 6.4 88.8 78.4 67.9 57.5 47.1 -
62 97.9 5.9 97.9 95.8 85.7 75.1 64.5 54.0 91.0 6.4 91.0 89.3 81.4 70.9 60.5 50.1
57 96.1 5.8 96.1 96.8 92.9 82.3 71.7 61.1 91.2 6.4 91.2 91.2 86.8 76.4 66.0 55.5
3000
77 136.5 5.8 66.4 54.5 42.6 - - - 126.2 6.5 62.5 50.8 39.2 - - -
72 126.9 5.8 83.9 72.0 60.1 48.2 - - 115.9 6.5 79.5 67.9 56.3 44.6 - -
67 117.3 5.9 101.4 89.5 77.6 65.7 53.8 - 105.6 6.5 96.6 85.0 73.3 61.7 50.0 -
62 103.6 5.9 103.6 103.6 92.6 80.7 68.8 56.9 94.5 6.4 94.5 94.5 87.8 76.1 64.5 52.9
57 101.8 5.9 101.8 101.8 100.4 88.5 76.6 64.6 94.8 6.4 94.8 94.8 93.7 82.1 70.4 58.8
3375
72 128.9 5.8 88.3 75.7 63.2 50.6 - - 118.6 6.5 84.9 72.3 59.8 47.2 - -
67 119.1 5.8 110.1 94.1 81.6 69.0 56.4 - 108.1 6.5 103.0 90.4 77.9 65.3 52.8 -
62 105.2 5.9 105.2 105.2 99.6 87.0 74.4 61.8 96.7 6.4 96.7 96.7 93.2 80.7 68.1 55.6
57 103.4 5.8 103.4 103.4 102.6 90.1 77.5 64.9 96.9 6.4 96.9 96.9 96.4 83.9 71.3 58.8
3750
72 130.9 5.8 92.7 79.5 66.2 53.0 - - 121.2 6.5 90.2 76.7 63.3 49.8 - -
67 121.0 5.8 118.7 98.7 85.5 72.2 59.0 - 110.5 6.5 109.4 95.9 82.4 69.0 55.5 -
62 106.8 5.8 106.8 106.8 106.5 93.2 80.0 66.7 98.9 6.4 98.9 98.9 98.7 85.2 71.8 58.3
57 104.9 5.8 104.9 104.9 104.9 91.7 78.4 65.2 99.1 6.4 99.1 99.1 99.1 85.7 72.2 58.7
95°F 105°F
1875
77 110.3 7.1 44.2 36.2 28.1 - - - 103.5 7.7 38.5 33.2 25.2 - - -
72 99.9 7.0 57.2 49.2 41.1 33.0 - - 93.1 7.6 54.2 46.2 38.2 30.3 - -
67 89.5 7.0 70.2 62.2 54.1 46.0 37.9 - 82.7 7.5 69.8 59.2 51.2 43.3 35.3 -
62 81.3 6.9 81.3 77.5 65.0 57.0 48.9 40.8 78.3 7.4 78.3 75.8 62.2 54.2 46.2 38.3
2250
77 112.2 7.1 49.0 39.8 30.7 - - - 103.5 7.8 45.5 36.5 27.4 - - -
72 101.6 7.1 63.2 54.0 44.9 35.7 - - 93.1 7.7 59.6 50.6 41.5 32.5 - -
67 91.0 7.0 77.4 68.2 59.1 49.9 40.7 - 82.7 7.5 73.7 64.7 55.7 46.6 37.6 -
62 82.7 6.9 82.7 80.2 71.0 61.8 52.7 43.5 78.2 7.4 78.2 76.6 67.5 58.5 49.5 40.4
57 84.9 6.9 84.9 83.7 74.5 65.3 56.1 47.0 80.0 7.4 80.0 78.7 69.7 60.7 51.6 42.6
2625
77 114.1 7.2 53.8 43.5 33.2 - - - 103.5 7.8 52.4 39.7 29.6 - - -
72 103.3 7.1 69.2 58.9 48.6 38.4 - - 93.1 7.7 65.0 54.9 44.8 34.7 - -
67 92.5 7.0 84.6 74.3 64.0 53.8 43.5 - 82.7 7.6 77.6 70.2 60.1 50.0 39.9 -
62 84.1 6.9 84.1 82.8 77.0 66.7 56.4 46.2 78.2 7.5 78.2 77.4 72.9 62.8 52.7 42.6
57 86.3 6.9 86.3 85.7 80.8 70.5 60.2 49.9 79.9 7.5 79.9 79.3 75.2 65.1 55.0 44.9
3000
77 115.9 7.2 58.6 47.2 35.8 - - - 103.4 7.9 59.4 43.0 31.8 - - -
72 105.0 7.1 75.2 63.8 52.4 41.0 - - 93.1 7.7 70.5 59.3 48.1 37.0 - -
67 94.0 7.1 91.7 80.4 69.0 57.6 46.3 - 82.7 7.6 81.6 75.7 64.5 53.3 42.1 -
62 85.5 7.0 85.5 85.5 83.0 71.6 60.2 48.8 78.1 7.5 78.1 78.1 78.2 67.1 55.9 44.7
57 87.8 7.0 87.8 87.8 87.0 75.7 64.3 52.9 79.9 7.5 79.9 79.9 80.8 69.6 58.4 47.2
3375
72 108.3 7.1 81.4 68.9 56.4 43.8 - - 97.2 7.8 76.7 64.4 52.1 39.8 - -
67 97.0 7.1 95.9 86.7 74.2 61.7 49.1 - 86.4 7.6 85.8 81.1 69.8 57.5 45.2 -
62 88.2 7.0 88.2 88.2 86.9 74.4 61.9 49.3 81.6 7.5 81.6 81.6 81.7 69.4 57.1 44.8
57 90.5 7.0 90.5 90.5 90.2 77.7 65.1 52.6 83.5 7.5 83.5 83.5 83.9 71.6 59.3 47.0
3750
72 111.6 7.2 87.7 74.0 60.3 46.6 - - 101.3 7.8 82.8 69.4 56.0 42.6 - -
67 100.0 7.1 100.0 93.1 79.4 65.7 52.0 - 90.0 7.7 90.0 86.6 75.0 61.6 48.2 -
62 90.9 7.0 90.9 90.9 90.9 77.2 63.5 49.9 85.1 7.5 85.1 85.1 85.1 71.7 58.3 44.9
57 93.3 7.0 93.3 93.3 93.3 79.7 66.0 52.3 87.0 7.5 87.0 87.0 87.0 73.6 60.2 46.8
