ZyXEL NBG-415N User’s Guide
95 Chapter 7 Advanced
The following table describes the labels in this screen.
Table 38 Advanced: Firewall
LABEL DESCRIPTION
Enable SPI Select this option to activate stateful packet inspection. Clear this check box to
disable this feature.
NAT Endpoint
Filtering
The NAT Endpoint Filtering options control how the router's NAT manages
incoming connection requests to ports that are already being used.
UDP Endpoint
Filtering
Select the end-point filtering option for UDP traffic.
TCP Endpoint
Filtering
Select the end-point filtering option for TCP traffic.
DMZ Host
Enable DMZ Select this option to activate the DMZ feature to protect the specified device on the
LAN.
DMZ IP
Address
Enter the IP address (in dotted decimal notation) of a computer which you want to
protect on the LAN. Or select a computer IP address from the drop-down list box.
Non-UDP/TCP/
ICMP LAN
Sessions
You can set your ZyXEL Device to recognize sessions initiated by a VPN
connection from the LAN to the Internet (WAN) even though the VPN connection
uses an unknown protocol type (any protocols other than UDP, TCP, and ICMP).
This feature allows a single VPN connection to a remote host without the need for
an ALG. This feature does not apply to DMZ hosts (if enabled). DMZ hosts can
handles these sessions.
Select Enable to allow a single VPN connection to a remote host. For multiple VPN
connections, the appropriate VPN ALG must be enabled.
Clear the checkbox to disable this feature. However, you must also disable the
appropriate VPN ALG to deactivate the VPN connection.
Application Level Gateway (ALG) Application
PPTP Select this option to allow multiple computers on the LAN to connect to a remote
network using the PPTP protocol.
