ZyXEL NBG-415N User’s Guide
Chapter 1 Getting Started 24
The following table describes the LEDs.
1.3 Rear Panel
The following figure shows the rear panel.
Table 1 Front Panel LEDs
LED COLOR STATUS DESCRIPTION
PWR Off The ZyXEL Device is not receiving power.
Green On The ZyXEL Device is receiving power and ready.
Blinking The ZyXEL Device is resetting to the factory defaults.
LAN1 ..
4
Off No device is connected to this port.
Green On An Ethernet device is connected to this port.
Blinking The ZyXEL Device is sending/receiving data on this port.
WAN Off The WAN connection is not ready, or has failed.
Green On The ZyXEL Device has a successful WAN connection for
Internet access.
Blinking The ZyXEL Device is sending/receiving data over the WAN port.
WLAN Off The WLAN is disabled.
Amber On Pre-N WLAN is enabled on the ZyXEL Device.
Blinking The ZyXEL Device is sending/receiving data over the pre-N
WLAN.
Green On IEEE 802.11b/g WLAN is enabled on the ZyXEL Device.
Blinking The ZyXEL Device is sending/receiving data over the IEEE
802.11b/g WLAN.
USB Off The USB port is not in use
Green Blinking (3
Times)
Windows Connect Now setup is successful.
Blinking
(Continuous)
Windows Connect Now setup is not successful.
