ZyXEL Communications NBG-415N - Manual (Page 81)

ZyXEL NBG-415N User’s Guide
81 Chapter 7 Advanced
7.5 Routing
Each remote node specifies only the network to which the gateway is directly connected, and
the ZyXEL Device has no knowledge of the networks beyond. For instance, the ZyXEL
Device knows about network N2 in the following figure through remote node Router 1.
However, the ZyXEL Device is unable to route a packet to network N3 because it doesn't
know that there is a route through the same remote node Router 1 (via gateway Router 2). The
static routes are for you to tell the ZyXEL Device about the networks beyond the remote
nodes.
Figure 50 Example of Static Routing Topology
To view the routing table configure static routes, click Advanced > Routing to display the
configuration screen.
N1 N2 N3
Router 1
Router 2
