ZyXEL NBG-415N User’s Guide
87 Chapter 7 Advanced
8 If you select Sentinel Services in the previous screen, the Service Categories screen
displays. Use this screen to configure category-based content filtering.
This screen varies depending on what you select in the Categories Selection field.
Apply Web Filter This field displays when you select Block Some Access.
Select this option to apply the web filters you configure in the Web Filter screen.
Apply Advanced
Port Filters
This field displays when you select Block Some Access.
Select this option to apply the web filters you configure in the Port Filter screen.
Filter Ports Click this button to display the fields you use to configure port filters.
Port Filter Rules
Enable Select this option to activate this rule. Clear this check box to deactivate this rule.
Name Enter a descriptive name for identification purposes.
Dest IP Start Enter the start of the destination IP address range.
Dest IP End Enter the end of the destination IP address range.
Protocol Select a protocol type from the drop-down list box.
Dest Port Start Enter the start of the destination port range.
Dest Port End Enter the end of the destination port range.
Save Click Save to save the settings in this part of the screen.
Clear Click Clear to start configuring this part of the screen again.
Access Control Rules List
Enable Select this option to activate the rule. Clear this check box to disable the rule
without deleting it.
Policy This field displays the name of the port filter policy you configured for this access
control rule.
Machine This field displays the IP or MAC address of the device to which this access control
rule is applied.
Schedule This field displays the name of the schedule to use.
Web Filter This field indicates whether web filters apply to this access control rule.
Logged This field indicates whether Internet access activities are logged.
Table 33 Advanced: Access Control: Wizard: Filtering Method (continued)
LABEL DESCRIPTION
