TESTING THE TOUCH RING

1. With the D

IAGNOSTICS

dialog box open, observe the T

ABLET

I

NFO

column as you test the tablet Touch

Ring. If you have more than one tablet connected to your system, be sure you have selected the tablet
you are testing from the T

ABLET

I

NFO

column.

2. Slide your finger around the entire circumference of the Touch Ring. As you touch and move your finger

along the Touch Ring, a L

EFT

T

OUCH

number will indicate your current finger position on the Touch Ring.

3. Press the Touch Ring toggle button to toggle between the four customizable states. As you cycle

between settings, a corresponding LED should illuminate. Within the D

IAGNOSTICS

dialog box, the

button state is also shown as L

EFT

B

UTTONS

.

If any of the functions are set to S

KIP

, the corresponding LED will be skipped in the toggle sequence.

4. When you are done, click on the C

LOSE

button to exit the dialog box.

Important: Remember that some applications can override and control the Touch Ring functions.
Consider closing any open applications except the Wacom Tablet control panel when testing the Touch
Ring. For details, see

using applications integrated for tablet control

.

TESTING THE EXPRESSKEYS

1. With the D

IAGNOSTICS

dialog box open, observe the T

ABLET

I

NFO

column as you test each ExpressKey.

If more than one tablet is connected to your system, be sure you have selected the tablet you are
testing from the T

ABLET

I

NFO

column.

2. Test the keys on your tablet by clicking them one at a time. Each time you press a key, its number will

be displayed next to the L

EFT

K

EYS

category.

3. On the tablet itself, verify also that a tablet ExpressKeys icon is visible for each corresponding

ExpressKey.

4. When you are done, click on the C

LOSE

button to exit the dialog box.

Important: Remember that some applications can override and control the ExpressKey functions.
Consider closing any open applications except the Wacom Tablet control panel when testing the
ExpressKeys. For details, see

using applications integrated for tablet control

.
