EF4270 Emulation Commands
9–20 3255 4073–002
The following representation of the graphics cell shows how the cell is defined
and which bits define which dots in the cell (bit 0 is the least significant bit; bit
7 is the most significant bit).
Bit Number
7 6 5 4 3 2 1
1st Byte o o o o o o o
2nd Byte o o o o o o o
3rd Byte o o o o o o o
4th Byte o o o o o o o
5th Byte o o o o o o o
6th Byte o o o o o o o
7th Byte o o o o o o o
8th Byte o o o o o o o
9th Byte o o o o o o o
Each line may have up to 25 graphics cells (full-dot graphics). The print line is
printed unidirectionally.
Use six Vertical Tab commands (0B) or one Line Feed command (0A) between
each line (8 lines/inch).
