39
OSD Operation (continued)
Extend and Update the Active Directory Schema
Step 1 - Create a New Attribute:
a) Open Control Panel Administrative Tools Active
Directory Schema.
b) In the left panel of the screen that comes up, right-click Attributes:
c) Select New Attribute.
d) In the warning message that appears, click Continue to bring up the
Create New Attribute dialog box.
e) Fill in the dialog box according to the example below and click OK
to complete step 1 of the procedure.
• Common Name – userprofile
• LDAP Display Name – userprofile
• Syntax – Unicode String
• Minimum – 1
• Maximum – 255
Note: The Unique X500 Object ID uses periods, not commas.
Step 2 - Extend the Object Class With the New Attribute:
a) Open Control Panel Administrative Tools Active
Directory Schema.
b) In the left panel of the screen that comes up, select Classes.
c) In the right panel, right-click person:
d) Select Properties; the person Properties page comes up with the
General tab displayed. Click the Attributes tab.
e) Select the Attributes tab and click the Add button:
Advanced Network Management Settings
(continued)
