LDAP Configuration — Active Directory
To allow authentication and authorization for the B064-Series KVM Switch via LDAP or LDAPS, the Active Directory’s LDAP Schema must be
extended so that an extended attribute name for the B064-Series KVM Switch – userprofile – is added as an optional attribute to the person class.
• Authentication refers to determining the authenticity of the person logging in.
• Authorization refers to assigning permission to use the device’s various features.
In order to configure the LDAP server, you will have to complete the following procedures: 1) Install the Windows 2003 Support Tools; 2) Install
the Active Directory Schema Snap-in; and 3) Extend and Update the Active Directory Schema.
OSD Operation (continued)
Install the Windows 2003 Support Tools
1. On your Windows Server CD, open the Support Tools folder.
2. In the right panel of the dialog box that comes up, double click SupTools.msi.
3. Follow along with the Installation Wizard to complete the procedure.
Install the Active Directory Schema Snap-in
1. Open a Command Prompt.
2. Key in regsvr32 schmmgmt.dll to register schmmgmt.dll on your computer.
3. Open the Start menu. Click Run and key in mmc /a. Click OK.
4. On the File menu of the screen that appears, click Add/Remove Snap-in, then click Add.
5. Under Available Standalone Snap-ins, double click Active Directory Schema, click Close and click OK.
6. On the screen you are in, open the File menu and click Save.
7. For Save in, specify the C:\Windows\system32 directory.
8. For File name, key in schmmgmt.msc.
9. Click Save to complete the procedure.
Creating a Start Menu Shortcut Entry
To create a shortcut entry on the Start Menu for the Active Directory Schema, do the following:
1. Right click Start; select: Open all Users Programs Administrative Tools.
2. On the File menu, select New Shortcut
3. In the dialog box that comes up, browse to or key in the path to schmmgmt.msc (C:\Windows\system32\schmmgmt.msc) and click Next .
4. In the dialog box that comes up, key in Active Directory Schema as the name for the shortcut, then click Finish .
