SubZones TraversalSubZone Bandwidth PerCall Mode:
Determines whether there is a limit on the bandwidth of any one traversal call being handled
by the system.
SubZones TraversalSubZone Bandwidth PerCall Limit: <1..100000000>
Specifies the bandwidth limit (in kbps) applied to any one traversal call being handled by the
system (applies only if Mode is set to Limited).
SubZones SubZone [1..100] Name:
Assigns a name to this subzone.
SubZones SubZone [1..100] Bandwidth Total Mode:
Determines whether this subzone has a limit on the total bandwidth of calls being used by its
endpoints at any one time.
SubZones SubZone [1..100] Bandwidth Total Limit: <1..100000000>
Sets the total bandwidth limit (in kbps) of this subzone (applies only if Mode is set to
Limited).
SubZones SubZone [1..100] Bandwidth PerCall Inter Mode:
Determines whether there is a limit on the bandwidth for any one call to or from an endpoint
in this subzone.
SubZones SubZone [1..100] Bandwidth PerCall Inter Limit: <1..100000000>
Specifies the bandwidth limit (in kbps) on any one call to or from an endpoint in this subzone
(applies only if Mode is set to Limited).
SubZones SubZone [1..100] Bandwidth PerCall Intra Mode:
Determines whether there is a limit on the bandwidth for any one call between two endpoints
within this subzone.
SubZones SubZone [1..100] Bandwidth PerCall Intra Limit: <1..100000000>
Specifies the bandwidth limit (in kbps) for any one call between two endpoints within this
subzone (applies only if Mode is set to Limited).
SubZones SubZone [1..100] Subnet [1..5] IP Address:
Specifies an IP Address used (in conjunction with the IP Prefix Length) to identify a subnet to
be assigned to this subzone.
SubZones SubZone [1..100] Subnet [1..5] IP PrefixLength: <0..128>
Specifies the number of bits of the Subnet IP Address which must match for an IP Address
to belong in this subzone.
Pipes Pipe [1..100] Name:
Assigns a name to this pipe.
Pipes Pipe [1..100] Bandwidth Total Mode:
Determines whether or not this pipe is enforcing total bandwidth restrictions. None: no
bandwidth available.
