53
11.2.13 11.2.13 11.2.13 11.2.13 GROUP:MOTOR RATING PARAMETERS GROUP:MOTOR RATING PARAMETERS GROUP:MOTOR RATING PARAMETERS GROUP:MOTOR RATING PARAMETERS
Register Function / Title Bank Mask Adjustment Range Multiplier
242 NUMBER OF MOTOR POLES 0 / 1 00FF 0001: (2)
0002: (4)
0003: (6)
0004: (8)
0005: (10)
0006: (12)
0007: (14)
0008: (16)
2
243 MOTOR RATED CAPACITY 0 / 1 FFFF 0001
∼
270F (0.1
∼
999.9) 0.1
244 MOTOR TYPE 0 / 1 0030 0000:Toshiba EQPIII motor (0)
0010:Toshiba STD motor (1)
0020:Other (2)

245 2 MOTOR RATED
VOLTAGE
(230 / 460v units)
0 / 1 00FF 0012
∼
0078 (90
∼
600) 5
246 (575v units) 001A ∼
00AC (130
∼
860)
247 MOTOR RATED
FREQUENCY 0 / 1 00FF 0000 ∼ 00C8 (0 ∼ 400) 2
248 MOTOR RATED RPM 0 / 1 FFFF 0000 ∼ 270F (0 ∼ 9999) 1
249 AUTO-TUNING ENABLE 0 0008 0000: Auto-tuning disabled (0)
0008: Auto-tuning enabled (1)

24A LOAD MOMENT OF
INERTIA 0 / 1 00C0 0000: Small (0)
0040: Medium (1)
0080: Large (2)
00C0: Very large (3)

