Diagnostics – Toshiba G3 TOSVERT-130 User Manual
Page 25
24
Table 3 : Input Terminal Monitor Word Format
Bit Terminal
Value
0
F
0: Terminal – CC open
1: Terminal – CC shorted
1
R
0: Terminal – CC open
1: Terminal – CC shorted
2
S1
0: Terminal – CC open
1: Terminal – CC shorted
3
S2
0: Terminal – CC open
1: Terminal – CC shorted
4
S3
0: Terminal – CC open
1: Terminal – CC shorted
5
S4
0: Terminal – CC open
1: Terminal – CC shorted
6
S5 (option)
0: Terminal – CC open
1: Terminal – CC shorted
Low Byt
e
7
S6 (option)
0: Terminal – CC open
1: Terminal – CC shorted
8 Reserved
9 Reserved
A Reserved
B Reserved
C Reserved
Always 0
D
S7 (option)
0: Terminal – CC open
1: Terminal – CC shorted
E
RES
0: Terminal – CC open
1: Terminal – CC shorted
High Byt
e
F
ST
0: Terminal – CC open
1: Terminal – CC shorted
9.3
9.3
9.3
9.3 Diagnostics
Diagnostics
Diagnostics
Diagnostics
When the drive trips, 1 byte of high-priority user diagnostics is supplied to the master.
The value of the diagnostics byte is the drive’s fault code. Refer to section 11.3 for a
list of drive fault codes.
