Group:utility parameters – Toshiba G3 TOSVERT-130 User Manual
Page 52
51
11.2.12
11.2.12
11.2.12
11.2.12 GROUP:UTILI
GROUP:UTILI
GROUP:UTILI
GROUP:UTILITY PARAMETERS
TY PARAMETERS
TY PARAMETERS
TY PARAMETERS
Register
Function / Title
Bank
Mask
Adjustment Range
Multiplier
21C
INDUSTRIAL
APPLICATIONS
(previous setting monitor for
read use only)
0 / 1
00FF
0000: Std. Shpmt. setting
(0)
0001: Pump application
(1)
0002: Fan application
(2)
0003: Conveyor application
(3)
0004: Hoist application
(4)
0005: Textiles application
(5)
0006: Machine tools appl.
(6)
21D
INDUSTRIAL
APPLICATIONS
(for write use)
(
∗∗∗∗
)
0 / 1
00FF
0000: Does nothing
(0)
0011: Pump application
(1)
0012: Fan application
(2)
0013: Conveyor application
(3)
0014: Hoist application
(4)
0015: Textiles application
(5)
0016: Machine tools appl.
(6)
21E
STANDARD SETTING MODE
SELECTION
(
∗∗∗∗
)
0 / 1
00FF
0000: Does nothing
(0)
0001: 50Hz std. Settings
(1)
0002: 60Hz std. Settings
(2)
0003: Factory settings
(3)
0004: Trip clear
(4)
0005: Save user-set param.
(5)
0006: TYPE 5 reset
(6)
0007: Initialize typeform
(7)
21F
COMMAND MODE
SELECTION
0 / 1
0007
0000: Only RS232C valid
(0)
0001: Terminal input valid
(1)
0002: Panel input valid
(2)
0003: Communication interface input
valid (3)
0004: local/remote valid
(4)
220
FREQUENCY MODE
SELECTION
0 / 1
0038
0000: Only RS232C valid
(0)
0008: Terminal input valid
(1)
0010: Panel input valid
(2)
0018: Communication/12-bit binary
interface input valid
(3)
0020: local/remote valid
(4)
221
PANEL OPERATION MODE
SELECTION
0 / 1
00FB
0000
∼
003F (0
∼
63)
(except 0004, 0008, 000C....)
1
222
PASS NUMBER
0 / 1
00FF
0000
∼
0063 (0
∼
99)
1
223
CPU VERSION
2 FFFF
(Monitor
only)
224
ROM VERSION
3 or 6
FFFF
(Monitor only)
225
EEPROM VERSION
1 FFFF
(Monitor
only)
226
INVERTER TYPEFORM
0
00FF
Refer to Table 9 (page 54)
227
STATUS MONITOR #1
DISPLAY SELECT
0 / 1
FFFF
0001
∼
0010 (1
∼
16)
1
228
STATUS MONITOR #2
DISPLAY SELECT
0 / 1
FFFF
0001
∼
0010 (1
∼
16)
1
229
STATUS MONITOR #3
DISPLAY SELECT
0 / 1
FFFF
0001
∼
0010 (1
∼
16)
1
22A
STATUS MONITOR #4
DISPLAY SELECT
0 / 1
FFFF
0001
∼
0010 (1
∼
16)
1
22B
FREQUENCY UNITS SCALE
FACTOR
0 / 1
FFFF
0000
∼
4E20 (0.00
∼
200.00)
0.01
22C
FREQUENCY DISPLAY
RESOLUTION
0 / 1
0003
0000: 1Hz
(0)
0001: 0.1Hz
(1)
0002: 0.01Hz
(2)
