Example Table Excerpt:
Register
Function / Title
Bank
Mask
Adjustment Range
Multiplier
26
MAXIMUM OUTPUT
FREQUENCY
(
∗∗∗∗
)
0 / 1
FFFF
0BB8
∼
9C40 (30.00
∼
400.00)
0.01
27
BASE FREQUENCY #1
0 / 1
FFFF
09C4
∼
9C40 (25.00
∼
400.00)
0.01
28
BASE FREQUENCY
VOLTAGE SELECT
(
∗∗∗∗
)
0 / 1
0030
0000: Input voltage level
(0)
0020: Automatic setting
(1)
0030: Stationary setting
(2)
29
MAXIMUM OUTPUT
VOLTAGE #1
0 / 1
FFFF
0000
∼
0258 (0
∼
600)
1
2A
REVERSE OPERATION
DISABLE SELECT
0 / 1
0020
0000: Reverse allowed
(0)
0020: Reverse not allowed
(1)
Other Programming Register Notes:
•
= All register numbers indicated are in hexadecimal notation (for example, 29 hex =
41 decimal). Occasionally, hexadecimal notation in this document may also take
the form of a number beginning with “0x”.
•
= Throughout this document, the abbreviations "LL", "UL", and "Fmax" will stand for
LOWER LIMIT FREQUENCY
,
UPPER LIMIT FREQUENCY
, and
MAXIMUM
OUTPUT FREQUENCY
, respectively.
•
= Reading from or writing to registers marked as "Reserved" will generate an
“invalid register” error (error code 0x0003)
•
= Certain parameter registers cannot be written to while the inverter is running.
These registers will be indicated by the character (
∗∗∗∗
). If an attempt is made to
write to these registers while the inverter is running, a “cannot execute” error
(error code 0x0001) will be generated.
•
= The parameter register data for all read/write registers with Bank information
listed as 0/1 will be retrieved from bank 0 (RAM) during reads and will be written
to both banks 0 and 1 (RAM and EEPROM) during writes.
•
= All parameters in
GROUP:COMMUNICATION SETTING PARAMETERS
(section
11.2.10) are retrieved by the drive from non-volatile memory upon inverter
initialization only. When any of these registers are modified, therefore, the drive
must be reset for the changed values to take effect.
•
= If the
COMMAND MODE SELECTION
or
FREQUENCY MODE SELECTION
parameters are changed while the drive is running, the change will not take effect
until the next time the drive is stopped.
