Viewing the
System Status
TANDBERG ENTRYPOINT
USER GUIDE
Registration Status . If Registered , the
Entrypoint is registered to the Gatekeeper with
below mentioned Address and Port.
Note that, since this
target system is not
an endpoint it is not
possible to use its IP
address to place calls to or
through the Entrypoint!
IP Address. Shows the IP address of the
Gatekeeper.
H.323 Gatekeeper Status
H.323 Gatekeeper Status
shows the current status of
the Gatekeeper registration.
To view H.323 gatekeeper
status, as indicated in the
screenshot shown here,
select
H.323 Status item of
the Status tab.
In case the Entrypoint is in direct mode or
in case the gatekeeper IP address is filled
in incorrectly, the Entrypoint will not be
registered with the Gatekeeper, and the
Registration status is stated as
Inactive .
About H.323 Status Registration Status Registered
Port . Shows the destination port number on
the Gatekeeper.
Registration Status Inactive
Registration Status Rejected
Registration status will show Rejected when:
Gatekeeper unreachable; the Entrypoint’s •
H.323 stack returns this reject message in
case the gatekeeper is down.
Duplicate alias; a system with an identical •
name has already been registered.
Authentication failure; Authentication •
ID and/or Authentication Password are
incorrect.
