Specifications
AMPLIFIER SECTION
Power Output (FTC) All channels 55 watts per channel min.
RMS. into 6 ohms two channel driven,
1,000 Hz with no more than 0.2 % total
harmonic distorsion.
Continuous power output (DIN)
All channels 50 watts per channel min.
RMS. into 6 ohms two channel driven,
1,000 Hz
Total Harmonic Distorsion 0.2 % at rated power
0.2 % at 1 watt output
IM Distortion 0.2 % at rated power
0.2 % at 1 watt output
Damping Factor 60 at 8 ohms
Input Sensitivity and Impedance
LINE (VIDEO 1, 2, TV, TAPE) 200 mV, 50 kohms
DIGITAL 2 (coaxial) 0.5 Vp-p, 75 ohms
Composite (VIDEO 1, 2) 1 Vp-p, 75 ohms
S-VIDEO (VIDEO 1) Y: 1 Vp-p, 75 ohms
C: 0.28 Vp-p, 75 ohms
Output Level and Impedance
REC OUT (TAPE, VIDEO 1) 200 mV, 2.2 kohms
PREOUT (Subwoofer, Center) 1 V, 2.2 kohms
Composite (Monitor out,VIDEO 1) 1 Vp-p, 75 ohms
S-VIDEO (Monitor out, VIDEO 1) Y: 1 Vp-p, 75 ohms
C: 0.28 Vp-p, 75 ohms
Component signal output (DVD out) Y: 1.0 Vp-p, 75 ohms,
Negative sync.
C
B /C R : 0.7 Vp-p, 75 ohms
Frequency Response 20 to 30,000 Hz : +/– 0.8 dB
Tone Control Bass : +/– 10 dB at 50 Hz
Treble : +/– 10 dB at 10,000 Hz
Signal-to-noise Ratio 100 dB (IHF)
Muting –
∞
dB
TUNER SECTION
Tuning Range FM: 87.50 to 108.00MHz (50 kHz steps)
AM: 530 to 1710 kHz (10 kHz steps)
Usable Sensitivity FM: Mono 11.2 dBf, 1.0 µV (75 ohms IHF)
0.9 µV (75 ohms DIN)
Stereo 17.2 dBf, 2.0 µV (75 ohms IHF)
23 µV (75 ohms DIN)
AM: 30 µV
50 dB Quieting FM: Mono 17.2 dBf, 2.0 µV (75 ohms)
Stereo 37.2 dBf, 20.0 µV (75 ohms)
Capture Ratio FM: 2.0 dB
Image Rejection Ratio FM: 40 dB
AM: 40 dB
IF Rejection Ratio FM: 90 dB
AM: 40 dB
Signal-to-noise Ratio FM: Mono 73 dB, IHF
Stereo 67 dB, IHF
AM: 40 dB
Alternate Channel Att. (+/– 400 kHz)
FM: Mono 55 dB, IHF
Selectivity FM: 50 dB, DIN
AM Suppression Ratio FM: 50 dB
Harmonic Distorsion FM: Mono 0.2 %
Stereo 0.3 %
AM: 0.7 %
Frequency response FM: 30 to 15,000 Hz (+/– 1.0 dB)
Stereo Separation FM: 45 dB at 1,000 Hz
30 dB at 100 to 10,000 Hz
Stereo Threshold FM: 17.2 dBf, 20 µV (75 ohms)
DVD SECTION
Signal readout system Optical non-contact
Linear velocity 3.49 m/s (Single Layer), 3.84 m/s (Dual
Layer)
Error correction system Reed Solomon Product Code
Signal system Standard NTSC
Video output 1.0 Vp-p, 75 ohms, Negative sync.
S Video output Y: 1.0 Vp-p, 75 ohms, Negative sync.
C: 0.286 Vp-p, 75 ohms
Component signal output Y: 1.0 Vp-p, 75 ohms, Negative sync.
C B ,C R : 0.7 Vp-p, 75 ohms
Frequency response 4Hz - 20kHz (44.1KHz),
4Hz - 22kHz (48KHz) , 4Hz - 44kHz
(96kHz)
Wow and flutter Below threshold of measurability
GENERAL
Power Supply Rating AC 120 V, 60Hz
Power Consumption 3.0 A
Dimensions (W x H x D) 435
Ч
145
Ч
414 mm
17 1 / 8
″ Ч
51 1 / 16
″ Ч
16 5 / 16
″
Weight 10.8 kg (23.8 lbs.)
Specifications and features are subject to change without notice.
