3.4.1
Setting IP and Control Preferences
An IP address is required for the SNMP or Telnet access. The factory default setting is 192.168.1.220. The
IP address can be configured manually or automatically as a DHCP client.
3.4.1.1
Setting IP Parameters Manually
To manually configure the IP address and control parameters, select 3 from the Management Options
screen. The IP and Control Preferences screen will appear.
IP and Control Preferences Screen
iConverter, Serial Agent
1: Set IP
192.168.1.220
2: Set Subnet Mask
255.255.255.0
3: Set Gateway
192.168.1.1
4: Chassis Number
1
5: Chassis Name (also sysName)
NMM
6: Enable/Disable TELNET
Enabled
7: Enable/Disable FTP
Disabled
8: Enable/Disable Soft Switch Reload
Disabled
9: TELNET Password
*****
10: FTP Password
11: Serial Password
Enter Choice, Management Options Screen(0), (H)elp, E(x)it >
To configure the IP address of the NMM, select 1 at the IP and Control Preferences screen, and press
<ENTER>. Backspace over the existing value, type the new value (in x.x.x.x format), and press <ENTER>.
To configure the subnet mask of the NMM, select 2 at the IP and Control Preferences screen, and press
<ENTER>. Backspace over the existing value, type the new value (in x.x.x.x format), and press <ENTER>.
To configure the gateway of the NMM, select 3 at the IP and Control Preferences screen, and press
<ENTER>. Backspace over the existing value, type the new value (in x.x.x.x format), and press <ENTER>.
To save the new values, select 0 and press <ENTER> to return to the Management Options screen, then
select 6 and press <ENTER> to Save Preference Changes.
