127
■
SWA-155X (subwoofer)
INPUT: RCA L/R/C/SL/SR/ subwoofer (500 mV/47 k
Ω
)
AMPLIFIER SECTION
Power output
Front:
15 W x 2 (6
Ω
/EIAJ)
Center:
15 W (6
Ω
/EIAJ)
Surround:
15 W x 2 (6
Ω
/EIAJ)
Subwoofer: 25
W
(3
Ω
/EIAJ)
Front:
11 W x 2 (6
Ω
/DIN)
Center:
11 W (6
Ω
/DIN)
Surround:
11 W x 2 (6
Ω
/DIN)
Subwoofer: 20
W
(3
Ω
/DIN)
Total harmonic distortion: 0.1% (Output: 5 W)
Signal-to-noise ratio: 100 dB (STEREO: IHF A 0.5 V input)
SPEAKER SECTION
Type: J’DRIVE system, 16 cm OMF cone
GENERAL
Power supply
AC 120 V, 60 Hz
AC 220–230 V, 50/60 Hz
AC 230–240 V, 50 Hz
Power consumption: 65 W
Power consumption (Max.): 135 W
Dimensions (W x H x D):185 mm x 299 mm x 312 mm
Weight: 8 kg
Others: Magnetic shielding (EIAJ)
■
D-M7 (speaker)
Type: 8 cm OMF cone (One for each)
Dimensions (W x H x D): 102 mm x 210 mm x 142 mm
Weight: Each 1.1 kg
Others: Magnetic shielding (EIAJ)
■
D-M3 (speaker)
Type: 8 cm OMF cone (One for each)
Dimensions (W x H x D): 85 mm x 120 mm x 112 mm
Weight: Each 0.6 kg
Others: Magnetic shielding (EIAJ)
■
RC-506M (remote controller)
Transmitter: Infrared
Signal range: Approx. 16 ft., 5 meters
Power supply: Two “AA/R6” batteries (1.5 V x 2)
Specifications and features are subject to change without notice.
