Onkyo PR-SC885 - Manual (Page 124)

124
Specifications
Amplifier Section
Video Section
Tuner Section
■ FM
■ AM
■
Digital Tuner
General
■ Video Input
■
Video Output
■
Audio Inputs
■
Audio Outputs
■ Control Terminal
Specifications and features are subject to change without
notice.
THD (Total Harmonic
Distortion)
0.05% (1 Vrms)
Input Sensitivity and
Impedance
200 mV/ 47 k Ω (LINE)
2.5 mV/47 k Ω (PHONO MM)
Output Level and
Impedance
200 mV/ 470 Ω (REC OUT)
Phono Overload 70 mV (MM 1 kHz, 0.5%)
Frequency Response 5 Hz–100 kHz/ +1 dB–3 dB (Direct mode)
Tone Control ±10 dB, 20 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 110 dB (LINE, IHF-A)
80 dB (PHONO, IHF-A)
Input Sensitivity/Output
Level and Impedance
1 Vp-p /75 Ω (Component and S-Video Y)
0.7 Vp-p /75 Ω (Component Pb/Cb,Pr/Cr)
0.28 Vp-p /75 Ω (S-Video C)
1 Vp-p /75 Ω (Composite)
Component Video
Frequency Response
5 Hz – 100 MHz, –3 dB
Tuning Frequency Range
87.5 MHz– 107.9 MHz
Tuning Frequency Range
530 kHz–1710 kHz
XM, SIRIUS, HD RADIO
Preset Channel 40
Power Supply AC 120 V, 60 Hz
Power Consumption: 1.1 A
Dimensions
(W
×
H
×
D)
435
Ч
194
Ч
448.5 mm
17-1/8"
Ч
7-5/8"
Ч
17-11/16"
Weight 13.5 kg
29.8 lbs.
HDMI IN 1, IN 2, IN 3, IN 4
Component IN 1 (DVD), IN 2, IN 3
Composite AUX 1, GAME/TV, CBL/SAT,
VCR/DVR, DVD, AUX 2
S-Video AUX 1, GAME/TV, CBL/SAT,
VCR/DVR, DVD, AUX 2
HDMI OUT (MAIN), OUT (SUB)
Component MONITOR OUT 1, MONITOR OUT 2
Composite VCR/DVR OUT, MONITOR OUT
S-Video VCR/DVR OUT, MONITOR OUT
Digital Inputs COAXIAL IN 1, IN 2, IN 3,
OPTICAL IN 1, IN 2, IN 3 (Front)
Analog Inputs PHONO, CD, TAPE, AUX 1, GAME/TV,
CBL/SAT, VCR/DVR, DVD, MULTI CH
(FRONT, CENTER, SUBWOOFER,
SURR, SURR BACK), AUX 2
Balance Inputs BALANCE L, BALANCE R
Multichannel Inputs 7.1 ch
Digital Output OPTICAL (OUT)
Analog Outputs TAPE, VCR/DVR, PRE OUT (FRONT,
CENTER, SUBWOOFER, SURR, SURR
BACK, ZONE 2, ZONE 3)
Balance Pre Outputs FL, FR, C, SL, SR, SBL, SBR, SW
Multichannel Pre
Outputs
7
Subwoofer Pre Outputs 1
Speaker Outputs
HDMI MAIN (FL, FR, C, SL, SR, SBL,
SBR, + ZONE 2 (L, R)
Phones PHONES
MIC Yes
RS232 1
Ethernet 1
IR Input/Output 2/1
12 V Trigger Out 3
