Regency ® P48-2 Zero Clearance Direct Vent Gas Fireplace 36
OPTIONAL FINISHING TRIM
NOTE: Remove both the Flush Louvers or Bay Louvers and the Flush Front or Bay Front prior
to installing the Finishing Trim.
1) Install the Finishing Trim sides as shown in the diagram, line up the holes in the side trim with
the holes in the fi rebox side.
2) Secure with 2 screws per side.
3) Loosen the 3 screws in the top inside edge of the fi rebox.
4) Slide the Finishing Trim Top over the Side Trim pieces and fi t the bottom bracket slots over
the screws. Tighten the 3 screws to secure.
DOUBLE SCREEN
DOOR
1) Pull out the top louver.
2) Center the screen door and hook over the
fl ush door.
Clip locations
Clip installed on right side.
3) Open the screen door(s) and secure the
screen door to the fl ush door front with 2
clips on the bottom left and right side.
INSTALLATION
