D Changing the Toner Bottle
269
5
• 3: Pull the green lever, and gently pull
out the toner bottle.
• 4: Hold a new bottle horizontally and
shake it 5 or 6 times.
• 5: Remove the outer cap.
Note
❒ Do not remove the inner cap.
• 6: Place the toner bottle in position,
then push it in until the green lever
clicks.
Note
❒ If you cannot get it to click in, pull
out the toner bottle a little, slightly
rotate it to the right by 10 – 20
°
, then
try again.
• 7: Return the lever under the toner bot-
tle to its original position.
• 8: Close the front cover of the machine.
1
2
ZBQT020E
5 6
ZBQT030E
ZBQT040E
1
2
ZBQT050E
ZBQT060E
