Regency P121/P121LC/P121RC/P131 Zero Clearance Room Sealed Gas Fireplace 5
INSTALLATION
INSTALLATION
CHECKLIST
1) Locate appliance
a) Room location, page 8.
b) Clearances to Combustibles,
page 9.
c) Mantle Clearances, page 9.
d) Framing & Finishing Requirements,
page 10.
e) Flueing Requirements, pages 11-19.
2) Assemble Top Standoffs, page (NOTE:
page 11 must be done before installing unit
into fireplace.)
3) Install flue, pages 19-21.
4) Make gas connections. Test the pilot. Must
be as per diagram. Page 22.
5) Install log set where indicated on
page 24-25.
6) Glass Door Removal (page 26), Louvers
or Grills (page 26), and Finishing Trim
(page 26).
7) Install optional Wall Switch, Remote Con-
trol, or Wall Thermostat, page 27.
8) Final check.
Before leaving this unit with the customer, the
installer must ensure that the appliance is firing
correctly and operation fully explained to cus-
tomer.
This includes:
1) Clocking the appliance to ensure the cor-
rect firing rate (rate noted on label 40,000
Btu/h NG, and 39,000 Btu/h LPG) after
burning appliance for 15 minutes.
2) If required, adjusting the primary air to
ensure that the flame does not carbon.
First allow the unit to burn for 15-20 min.
to stabilize.
CAUTION: Any alteration to the product
that causes sooting or carboning that
results in damage is not the responsi-
bility of the manufacturer.
IMPORTANT:
SAVE THESE
INSTRUCTIONS
The Regency P121/P121LC/P121RC/P131-NG
or P121/P121LC/P121RC/P131-LPG Room
Sealed Gas Fireplace must be installed in ac-
cordance AG601 and NZS 5261 and with these
instructions. Carefully read all the instructions
in this manual first. Consult the "authority having
jurisdiction" to determine the need for a permit
prior to starting the installation. It is the respon-
sibility of the installer to ensure this fireplace is
installed in compliance with manufacturer's
instructions and all applicable codes.
BEFORE YOU START
Safe installation and operation of this appliance
requires common sense, however, we are
required to make you aware of the following:
GENERAL SAFETY
INFORMATION
1) The appliance shall be installed in accord-
ance with the manufacturer's installation
instructions, local gas fitting regulations,
municipal building codes, water supply reg-
ulations, electrical wiring regulations, with
AS5601-2004 (AGA gas installation code)
NZS 5261 (New Zealand)
2) See general construction and assembly
instructions. The appliance and flue should
be enclosed.
3) This appliance must be connected to the
specified flue and termination cap to the
outside of the building envelope. Never flue
to another room or inside a building. Make
sure that the flue is fitted as per Flueing
instructions.
4) Inspect the flueing system annually for
blockage and any signs of deterioration.
5) Flueing terminals shall not be recessed into
a wall or siding.
6) Any safety glass removed for servicing
must be replaced prior to operating the
appliance.
7) To prevent injury, do not allow anyone who
is unfamiliar with the operation to use the
fireplace.
8) Wear gloves and safety glasses for pro-
tection while doing required maintenance.
9) Be aware of electrical wiring locations in
walls and ceilings when cutting holes for
termination.
10) Under no circumstances should this appli-
ance be modified. Parts that have to be
removed for servicing should be replaced
prior to operating this appliance.
11) Installation and any repairs to this appliance
should be done by a authorized service
person. A authorized service person should
be called to inspect this appliance annually.
Make it a practice to have all of your gas
appliances checked annually.
12) Do not slam shut or strike the glass door.
13) Under no circumstances should any solid
fuels (wood, paper, cardboard, coal, etc.)
be used in this appliance.
INSTALLATION AND REPAIR SHOULD
BE DONE BY A AUTHORIZED SERVICE
PERSON. THE APPLIANCE SHOULD BE
INSPECTED BEFORE USE AND AT
LEAST ANNUALLY BY A AUTHORIZED
SERVICE PERSON. MORE FREQUENT
CLEANING MAY BE REQUIRED DUE TO
EXCESSIVE LINT FROM CARPETING,
BEDDING MATERIAL, ETC. IT IS IMPER-
ATIVE THAT CONTROL COMPART-
MENTS, BURNERS AND CIRCULATING
AIR PASSAGEWAYS OF THE APPLI-
ANCE BE KEPT CLEAN.
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED OUT
OF TRAFFIC AND AWAY FROM FURNI-
TURE AND DRAPERIES.
WARNING: FAILURE TO INSTALL THIS
APPLIANCE CORRECTLY WILL VOID
YOUR WARRANTY AND MAY CAUSE A
SERIOUS HOUSE FIRE.
CLOTHING OR OTHER FLAMMABLE MA-
TERIAL SHOULD NOT BE PLACED ON
OR NEAR THE APPLIANCE.
CHILDREN AND ADULTS SHOULD BE
ALERTED TO THE HAZARDS OF HIGH
SURFACE TEMPERATURES, ESPECIAL-
LY THE FIREPLACE GLASS, AND
SHOULD STAY AWAY TO AVOID BURNS
OR CLOTHING IGNITION.
YOUNG CHILDREN SHOULD BE
CAREFULLY SUPERVISED WHEN THEY
ARE IN THE SAME ROOM AS THE AP-
PLIANCE.
Emissions from burning wood or gas could
contain chemicals known to the State of
California to cause cancer, birth defects or
other reproductive harm.
Note: These units are
non-load bearing.
14) The appliance area must be kept clear and
free of combustible materials, (gases and
other flammable vapours and liquids).
