Regency P121/P121LC/P121RC/P131 Zero Clearance Room Sealed Gas Fireplace

26

GLASS DOOR

REMOVAL

1) Remove the 8 screws that secure the

glass door.

INSTALLATION

2) Pull the door slightly out on an angle and

then lift up and pull completely out.

3) P131 & P121LC/P121RC Corner Model:

Remove the 6 screws that secure the

glass door and repeat step 2.

FINISHING TRIM

1) Slide the Side Finishing Trim up into the slot

in the top flange of the fireplace. Push tight

against the magnet at the base of the unit.

LOUVERS & GRILLS

1) Attach the screws provided to the top left

and right corners.

NOTE: Do not tighten the screw entirely,

ensure that some room is left to be able

to hang the grill or louver over the screw.

2) Hang the Top Louver or Grill onto the 2

screws in the top fireplace opening.

3) Attach the Bottom Louver or Grill to the

hinges on the bottom flange of the fireplace.

P121 & P131 Corner Models

4) Attach the screws provided to the top and

bottom, left and right corners similar to step

1.

5) Hang the top and bottom louver or grill onto

the screws in the top and bottom, left and

right sides of the fireplace opening.

The Top and Bottom Side Louver or Grill is

installed the same way.

2) Slide the Corner Finishing Trim up into the

slot in the top flange of the fireplace. Push

tight against the magnet at the base of the

unit.

Slide Trim into

slot.

Push trim tight

against magnet.

Slide Trim into

slot.

Push trim tight

against magnet.
