Chapter 6. Troubleshooting
6.1 Flowchart to Remedy the Troubles
Figure 6.1 shows the flowchart to remedy the troubles from when power to the emulator is activated
until the emulator debugger starts up. Check this while the target system is disconnected. For the latest
FAQs visit the following URL.
http://www.renesas.com/en/tools
Figure 6.1 Flowchart to remedy the troubles
Not normal
Normal
Not normal/Error displayed
Normal
Not normal/Error displayed
Normal
Turning on the power of PC4701
Program window of emulator debugger displayed
Init dialog box of emulator
debugger displayed
1. Check the operating environment etc. of the emulator
debugger.
See the user's manual of the emulator debugger.
2. Reinstall the emulator debugger.
1. Check emulator system connections.
See, "3.5 Connecting the PC4701 and Emulation Pod"
(page 34).
2. Redownload the firmware.
See "4.2 Downloading Firmware" (page 48).
3. Restart the PC4701 system.
EMEM dialog box of emulator
debugger displayed
Error displayed
See "6.2 (4) Errors Occur When the Emulator Debugger Starts
Up (When the target system is connected)" (page 67).
See "6.2 (3) EMEM Dialog is Not Displayed When the Emulator
Debugger Starts Up (When the target system is not connected)"
(page 67).
Front panel LED of PC4701
