Renesas Emulation Pod for M16C/80 Group MCUs M30803T-RPD-E - Manual (Page 28)

( 26 / 74 )
Table 3.1 Switch settings of the M30803T-RPD-E (1/3)
Signal Switch Setting Description
P87/X
CIN
P86/X
COUT
SW1
SW2
X
OUT
RDY*/
HOLD*
SW3
SW4
Connects the P87/X
CIN
pin of MCU to the target
system (uses the P87/X
CIN
pin as Port P87).
Connects the P87/X
CIN
pin of MCU to the sub-clock
oscillator circuit (32.768 kHz) on the emulation
pod.
Connects the P86/X
COUT
pin of MCU to the target
system (uses the P86/X
COUT
pin as Port P86).
Connects the P86/X
COUT
pin of MCU to the target
system (uses the P86/X
COUT
pin as X
COUT
).
X
OUT
pin of MCU is unconnected.
Connects the X
OUT
pin of MCU to the target system.
Pulls up the RDY* and HOLD* pins of MCU with a
resistance of 33 k
Ω .
Be sure to set this when using the emulation pod
while not connecting the target system.
Connects the RDY* and HOLD* pins of MCU to the
target system.
P86/X
COUT
pin of MCU is unconnected.
