2.2 Package Components
The M30803T-RPD-E package consists of the following items. When unpacking, check to see if your
M30803T-RPD-E contains all of these items.
Table 2.1 Package components
Please keep the M30803T-RPD-E’s packing box and cushion material in your place for reuse at a later
time when sending your product for repair or other purposes. Always use these packing box and
cushion material when transporting M30803T-RPD-E.
If any of these items are missing or found faulty, please contact your local distributor. Also, if there
is any question or doubt about the packaged product, contact your local distributor.
2.3 Other Tool Products Required for Development
To bring forward programs development on the M16C/80 Group MCUs, the products listed below
are necessary in addition to those contained package above. Get them separately.
Table 2.2 Other tool products
* To purchase these products, contact your nearest distributer.
* For details on the IC51-1004-51, contact Yamaichi Electronics Co., Ltd.
Product
Emulator main unit
Emulator debugger
Product name
PC4701
M3T-PD308
FLX-144NSD
100LCC-QSD
100LCC-DMS + FLX-100NSD
100LCC-DMS + DUMMY100S
100LCC-DMS + DIRECT100S
100LCC-DMS + FLX-100NRB
IC51-1004-051 etc.
Item
M30803T-RPD-E emulation pod main unit
FLX120-RPD flexible cable for connecting emulator main unit
FLX160-PRB converter board for connecting FLX160 to M30800T-PTC
(mounted on FLX160)
M30800T-PTC converter board for 100-pin LCC package
OSC-2 oscillator circuit board (bare-board)
Hardware tool user registration FAX sheet (English)
Hardware tool user registration FAX sheet (Japanese)
M30803T-RPD-E user's manual (this manual)
M30803T-RPD-E user's manual (Japanese)
Quantity
1
1
1
1
1
1
1
1
1
144-pin 0.5-mm-pitch LQFP
(144P6Q-A)
100-pin 0.5-mm-pitch LQFP
(100P6Q-A)
100-pin 0.65-mm-pitch QFP
(100P6S-A)
Converter boards
Notes
Required
Required
Required according to the foot
pattern of the target system
(see 3.6 "Connecting the Target
System" on page 36)
100-pin LCC socket
