(2) Connecting the Cable to the Emulation Pod
Figure 3.10 shows how to connect the FLX120-RPD and the emulation pod.
Figure 3.10 Connecting emulation pod and FLX120-RPD
CAUTION
Note on Connecting the Cable:
• Always shut OFF power before connecting the cable. The power ON state could
destroy internal circuits.
Note on Securing the Screws:
• After connecting the emulator main unit to the cable, be sure to secure the screws.
