Operational Specifications
3.2.5 Jumper Switch Setting when Using Development Tool
Rev.1.00 Oct 09, 2008 3-22
REJ11J0021-0100
3
3.2.5 Jumper Switch Setting when Using Development Tool
The SH7137 emulator-related signals (FWE/ASEBRKAK
_____________________
/ASEBRK
________________
, TDI, TDO) are multiplexed with o flash writing control
pin. When using the development tools such as E10A-USB emulator and Flash Development Toolkit (FDT), set the jumper
switches as shown in Table 3.2.8.
Table 3.2.8 Jumper Setting for Each Connector
Setting
Tool Connector
JP7 to JP10
Remarks
E10A-USB emulator H-UDI connector (J2) Don’t care Connect “2-3” when using SRAM.
FDT Serial port connector (J3) “1-2” Connect TXD1,and RXD1 pins
(required)
