Operational Specifications

3.1.8 GND Connector (J15)

Rev.1.00 Oct 09, 2008

3-15

REJ11J0021-0100

3

3.1.8 GND Connector (J15)

The M3A-HS37 is provided with a GND connector.

The pin assignments are shown and listed in Figure 3.1.9 and Table 3.1.14.









Figure 3.1.9 Pin Assignments for GND Connector (J15)

Table 3.1.14 Pin Assignments for GND Connector (J15)

No. Signal

Name

1 GND

2 GND

3 GND
