Operational Specifications
3.1.6 Expansion Connectors (J8 to J12)
Rev.1.00 Oct 09, 2008 3-11
REJ11J0021-0100
3
Table 3.1.10 lists the pin assignments for the expansion connector (J10).
Table 3.1.10 Pin Assignments for Expansion Connector (J10)
No. Signal Name Also connected to
1 PE21/WRL/TIOC4DS/TRST H-UDI connector (J2)
2 PE20/TIOC4CS/TMS H-UDI connector (J2)
3 PE19/RD/TIOC4BS/TDO H-UDI connector (J2)
4 PE18/CS1/TIOC4AS/TDI H-UDI connector (J2)
5 PD10/SSO -
6 PD9/SSI -
7 PD8/SCK2/SSCK -
8 PB7/CS1/CRx0 JP13 – RCAN IN
9 PB6/WAIT/CTx0 JP12 – RCAN OUT
10 PB1/BREQ/TIC5W -
11 PB0/BACK/TIC5WS -
12 PA9/WAIT/TCLKD/POE8/TXD2 -
13 PA8/WRL/TCLKC/POE6/RXD2 -
14 PA7/TCLKB/POE5/SCK2/ -
15 --- -
16 --- -
17 --- -
18 --- -
19 --- -
20 GND -
